High sensitivity (0.1LUX)

Wider Dynamic Range

Dual Voltage and Lower Power consumption＜1.8W

Speed white balance (1FIELD), 540 TVL,

Super high resolution

3 axis bracket

SNR(Super Noise Reduction)

IR function; Water proof / Armor.



	SIN-210A	YR-210B	YR-210C	YR-210D
sensor	1/3 SONY CCD
TV System	PAL/NTSC
Sync	Internal
Resolution	450 Line	540 Line	450 Line	540 Line
S/N ratio	≥50 dB
Mini Illumination	0.1 Lux(F1.2)
AGC	+18 dB Max
BLC	NO/OFF
AEC	NO/OFF
Mirror	NO/OFF
Voltage	DC 12V		DC 12/AC 24V
Power Comsuption	<250mA(DC 12V)/160mA(AC 24V)
Lens	3.5～8mm
IR distance	15M
Operation temp	-10 ℃ To 50 ℃ (Within85%RH)
Storage temp	-20 ℃ To 65 ℃ (Within85%RH)
Dimension	92.5mm(H)×139mm(D)
