| C22G OPS Specification |
|
|
| C22G OPS |
Ver 1.2 |
|
| CPU |
Intel Ivy Bridge i3/i5/i7 ULV BGA 17W
Support Configurable TDP
Support Y Series CPU |
|
| Chipset |
Intel Panther Point Chipset HM76 |
|
| Graphic |
DX11, Intel GMA HD4000 |
|
| Captative TOUCH Panel |
10 points Capacitive Multi-Touch |
|
| EMR Touch(Option) |
EMR Digitizer touch |
|
| Panel |
11.6'' 1366*768 (16:9) eDP Panel, Display angle up to 140 Degree
Up to 350nit, 250nit as optional |
|
| System Memory |
DDR3 1066 /1333MHz one DDR3 SO-DIMM slot Support up to 8G
1600MHz
Support DDR3L(Optional) |
|
| Storage |
1 full size MSATA port, support SATA 3.0 |
|
| Intenal MIC |
1 Built-in MIC
Dual Array Digital Mic（option） |
|
| Speakers |
2 Stereo Speakers |
|
| I/O Ports |
Combo Mic input & Line out x 1
DC-in x 1
Micro HDMI1.4a port x 1
USB 3.0 Port x 2
Card Reader（TF Card SD2.0)）x 1 |
|
| WLAN |
1 half size Mini PCI-E V1.2 slot
Support HMC WIFI card and WIFI+BT4.0 card
2 Antenna |
|
| 3G &GPS SOLUTION(OPTION) |
NGFF slot * 1
Support 3G&GPS combo card
GPS Antenna *1
3G Antenna *1
Micro Sim Card Slot *1 |
|
| SENSOR |
Accelerometer
Gyroscope
e-compass (option)
Ambient light sensor (option) |
|
| Digital camera (Front) |
HD 720p/30fps/Indicator LED, 1.0M
Ambient light sensor as Optional |
|
| Digital camera (Rear) |
2.0M /Indicator
5.0M /Indicator LED (option) |
|
| KB (OPTION) |
BT or USB Magnetic Pulling Keyboard (US, 83 Keys) |
|
| Power |
Input: 110~ 240V AC; DC 19V, @40W |
|
| Battery |
4Cell(2S2P)6000mAh Li-ion polymer Battery Pack
4cell(2S2P)9000mAh Li-ion polymer Battery Pack（Option） |
|
| Dimension |
302*196*13.5mm |
|
| Weight |
1.08Kg (with 9000mAh Battery/EMR Digitizer Touch/EMR Touch Pen/3G&GPS Combo Module)
0.95Kg (with 6000 mAh Battery, without EMR Digitizer Touch/EMR Touch Pen/3G&GPS Combo Module) |
|
| Operation System |
Win 8 |
|
| Option Summary |
□ EMR Digitizer touch & Touch PEN
□ Panel 350nit or 250nit
□ Support DDR3L Memory
□ Digital Dual Array Mic
□ Ambient light sensor on Front Camera
□ e-compass sensor
□ 3G &GPS Port & Antenna
□ 3G &GPS Combo module
□ Rear Camera 2.0M or 5.0M
□ Battery 4cell 9000mAh or 4cell 6000mAh
□ BT or USB Keyboard
□ Accessory --- Micro HDMI to VGA CABLE (Option)
□ Accessory --- USB to LAN CABLE (Option) |
|
