Technical Specification of Indoor Curtain LED Display
|
No |
Item |
Parameter |
|
1 |
Pitch (mm) |
20 |
|
2 |
LED Standard |
DIP546 |
|
3 |
LED Arrangement |
2R1G1B |
|
4 |
Brightness (cd/m^2) |
≥6000 |
|
5 |
Density (Real) (dots/m^2) |
2500 |
|
6 |
Density (Virtual) (dots/m^2) |
10000 |
|
7 |
Module Size (mm) |
(L)=320; (H)=160; |
|
8 |
Module Resolution (dots) |
16*8 |
|
9 |
Cabinet Size (mm) |
(L)=1280 ; (H)=960 ; (W)=150 |
|
10 |
Resolution/Cabinet |
64*48 |
|
11 |
Cabinet Material |
Iron Cabinet |
|
12 |
Waterproof Material |
Silicone |
|
13 |
Waterproof Size |
Display Size |
|
14 |
Angle-Level (angle) |
110 (Right/Left) |
|
15 |
Angle-Vertical (angle) |
40 (Up/Down) |
|
16 |
Best-Vision-Distance (m) |
16-130 |
|
17 |
Gray Grade (Rank) |
≥16384 |
|
18 |
Display Color (Color) |
Full Color (16.7m) |
|
19 |
Display Mold |
Virtual Image Control |
|
20 |
Drive Mode |
Static, Constant Current Driver |
|
21 |
Control Mode |
Synchrony Transfer |
|
22 |
In-Interface |
RS422 |
|
23 |
Connecting Series |
VGA |
|
24 |
Cabinet Weight (kg/pc) |
80 |
|
25 |
Max Power Consumption (KW/m^2) |
900 |
|
26 |
Avg Power Consumption (KW/m^2) |
400 |
|
27 |
Life Time (hr) |
100000 |
|
28 |
Voltage (V) |
AC: 220 /380 ±10 %, 50 Hz |
|
29 |
Control Distance (m) |
< 100 | |
|
|
|
