| Classification |
Pitch 6 |
Pitch 7.62 |
Pitch 8 |
Pitch 10 |
P12 |
| Pixel pitch(mm) |
6(physical) |
7.62(physical) |
8(physical) |
10(physical) |
12(physical) |
| Pixel configuration |
1R1G1B |
1R1G1B |
1R1G1B |
1R1G1B |
1R1G1B |
| Type of indoor series available |
SMD 1 in 1, SMD 3 in 1, dot matrix |
| Pixel denstiy/ sqm |
27777dots |
17222dots |
15625dots |
10000dots |
7944 dots |
| Module size(mm*mm) |
192*96(h)-SMD. 192*192(h)-dot matrix |
244*122(h)-SMD. 244*244(h)-dot matrix |
256*128(h) |
320*160(h) |
384*192(h) |
| Module pixel( dots) |
32*16-SMD 32*32-dot matrix |
32*16-SMD 32*32-dot matrix |
32*16 |
32*16 |
32*16 |
| Standard size of cabinet(mm*mm) |
960*768 |
976*732 |
1024*768 |
1280*960 |
1152*768 |
| Cabinet pixel( dots) |
160*128 |
128*96 |
128*96 |
128*96 |
96*64 |
| Best view angle |
140° |
140° |
140° |
140° |
140° |
| Maximum power comsuption(W/sqm) |
1000 |
550 |
600 |
800 |
700 |
| Brightness cd/sqm |
≥ 1500 |
≥ 1200 |
≥ 1000 |
≥ 15 00 |
≥ 1000 |
| Driving method |
1/8 constant driving |
1/4 constant driving |
| Display color |
256*256*256 |
| Refresh frequency |
300HZ |
| Frame frequency |
30HZ |
| Working Voltage |
AC220/110±10% |
| Working environment temperature |
-40º С .. +50º С |
| Life span |
>100000hours |
