Specification of Outdoor LED display
| Classification |
Pitch10 |
Pitch 12 |
Pitch 14 |
Pitch 16 |
P18 |
Pitch 20 |
Pitch 22 |
Pitch 25 |
Pitch31.25 |
| Pixel pitch(mm) |
10(physical) |
12(physical) |
14(physical) |
16(physical) |
18(physical) |
20(physical) |
22(physical) |
25(physical) |
31.25 |
| 6(virtual) |
8(virtual) |
10(virtual) |
12.5(virtual) |
| Pixel configuration |
1R1G1B |
2R1G1B |
2R1G1B |
2R1G1B |
2R1G1B |
2R1G1B |
2R1G1B |
2R1G1B |
4R2G2B |
| LED package |
DIP346 |
DIP346 |
DIP546 |
DIP546 |
DIP546 |
DIP546 |
DIP546 |
DIP546 |
DIP546 |
| Pixel denstiy/ sqm |
10000dots |
6844dots |
5102dots |
3906dots |
3086 dots |
2500dots |
2066dots |
1600dots |
1024dots |
| 27777 dots |
15625 dots |
10000dots |
6400dots |
| Module size(mm*mm) |
320*160(h) |
192*192(h) |
224*112(h) |
256*128(h) |
288*144(h) |
320*160(h) |
352*176(h) |
200*200(h) |
125*250(h) |
| Module pixel( dots) |
32*16 |
16*16 |
16*8 |
16*8 |
16*8 |
16*8 |
16*8 |
8*8 |
4*8 |
| Standard size of cabinet(mm*mm) |
1280*960 |
1152*768 |
896*896 |
1024*768 |
1152*864 |
1280*960 |
1056*1056 |
1000*1000 |
1000*1000 |
| Cabinet pixel( dots) |
128*96 |
96*64 |
64*64 |
64*48 |
64*48 |
64*48 |
48*48 |
40*40 |
32*32 |
| Best view angle |
110° |
110° |
110° |
110° |
110° |
110° |
110° |
110° |
110° |
| Maximum power comsuption(W/sqm) |
750 |
700 |
600 |
1000 |
950 |
900 |
700 |
600 |
600 |
| Brightness cd/sqm |
≥5 000 |
≥5000 |
≥5 500 |
≥ 7500 |
≥ 6500 |
≥ 60 00 |
≥ 5000 |
≥ 4500 |
≥ 5500 |
| Driving method |
1/4 constant driving |
1/2 contant driving |
Constant static |
| Display color |
256*256*256 |
| Refresh frequency |
300HZ |
| Frame frequency |
60HZ |
| Protection Level |
Front: IP 65; back: IP43 |
| Working Voltage |
AC220/110±10% |
| Working environment temperature |
-40º С .. +50º С |
| Life span |
>100000hours | |
|
|
|
